XPR-10XLS 10,000 Capacity / Symmetric / Adjustable Width / Screw Pads / HIGH RISE
$ 2,996
$ 6,195
Elevate Efficiency with Unmatched Lifting Height
Designed for tall technicians who demand ergonomic comfort, the 10APX Symmetrical Lift delivers superior reach, allowing you to work upright without strain. With its enhanced high-rise design and customizable options like an extension kit or Low-Pro™ arms, this lift adapts to any vehicle, making it the ultimate solution for modern automotive shops.
10,000-lb. Capacity / Symmetric Design / Adjustable Width / High-Rise Screw Pads
KEY FEATURES & BENEFITS
10,000-lb. Lifting Capacity: Built to handle heavy-duty vehicles with ease.
Expandable Top Beam: Adjust width for wide or narrow configurations.
Double-Telescoping Screw Pads: Precision adjustment (2") for versatile vehicle support.
79.75" Max Lifting Height + Pad: Keep tall technicians comfortable and productive.
Dual Hydraulic Direct-Drive Cylinders: Smooth, rapid lifting in just 45 seconds (75" rise).
Enhanced Safety: Padded overhead shutoff bar, automatic arm restraints, and 3"-spaced safety locks on rust-resistant plated hardware.
Durability Redefined: Single-piece columns, oversized 59" carriage, and maintenance-free UHMW bearings ensure long-term reliability.
Advanced Ergonomics: Lowered arm tubes and 63 mm stackable adapters standard for seamless workflow.
ALI Certified: Meets rigorous industry safety and performance standards.
TECH SPECS
Motor: 220 VAC / 60 Hz / 1 Ph | Noise Level: 45 dB
Drive-Thru Clearance: 93"–106" | Base Plate: 17" x 19" A36 steel
Front/Rear Arm Reach: 25.5"–49.5" (front) / 32.25"–52.5" (rear)
Height Overall: 157" | Max Load per Arm: 2,500 lbs.
WHY CHOOSE THE 10APX?
The 10APX replaces the XPR-10XLS with refined engineering, including oversized cable sheaves to reduce fatigue and a self-lubricating Dura-Glide™ bearing system for effortless operation. Perfect for shops prioritizing technician comfort, vehicle versatility, and industrial-grade performance.
Upgrade your shop with the 10APX—where innovation meets ergonomic excellence.
(Optional extensions and Low-Pro™ arms available. Lift arms shown with optional foot guards.)
MODEL: 10APX
STYLE: Symmetric High-Rise
CERTIFICATION: ALI Certified
